Industrial Media Converter
Industrial 2x10/100/1000Base-Tx to 1000Base-Fx media converter
• Supporting Two 10/100/1000M copper and one 1000M Optical Port
• Optical port SC/ST/FC optional and distance 2~120km optional
• Optional 24V/220V power input
• Industrial IP40 Protection grade
• Support Din-rail and wall-mount installation
- Description
- Parameter
- Application
- Download
- Related
HT302GI series industrial 10/100/1000M 2GE+1GF media converter support the conversion from 2x10/00/1000M copper to 1000M optical. Redundant power supply design, wide voltage range input, and provide overload and reverse protection. Wide temperature model can be selected, strong anti-electromagnetic interference ability, fully meet the harsh industrial application environment.
Highlights:
‧EMC Certified for Industrial Standards
‧4KV Surge Protection
High MTBF
‧Long Life Parts
‧Rigorous Standards
‧Strict Quality Checks in Factory
‧5 Years Warranty
‧Fan-less and Rugged Design
|
IEEE Standard
|
|
IEEE 802.3
|
10BaseT
Ethernet
|
|
IEEE
802.3u
|
100BaseT(X)
and 100BaseFX Fast Ethernet
|
|
IEEE
802.3ab
|
1000BaseT(X)
Ethernet
|
|
IEEE
802.3z
|
1000BaseX
Ethernet
|
|
IEEE 802.3x
|
Flow Control（flow control）
|
|
Switching Feature
|
|
MAC address table
|
2K
|
|
Packet Caching
|
1Mbit
|
|
Processing method
|
Store and forward
|
|
Interface
|
|
RJ45 port
|
x2
|
|
Fiber
|
x1, SM/MM optional, SC/ST/FC optional,
dual fiber/single fiber optional
|
|
Fiber transmission distance
|
MM 550m/2km，SM 20km/40km/60km/80km/120km optional
|
|
LED
|
PWR, TP/Fx Link/Act, Fail
|
|
Power
|
|
24V input
|
6-Pin, dual power input, 12~48VDC
wide range
|
|
220V input
|
6-Pin, dual power
input, 85~264VAC/77~300VDC wide range
|
|
Power consumption
|
Max 3W
|
|
Power protection
|
Reverse connection protection and
overload protection
|
|
Environment
|
|
Standard operation temperature
|
-10 ~ 60℃
|
|
Wide range operation temperature
|
-40 ~ 75℃
|
|
Storage temperature
|
-40 ~ 85°C
|
|
Relative humidity
|
5 ~ 95% (non-condensation)
|
|
Physical
|
|
Housing
|
IP40 Aluminium alloy
|
|
Installation way
|
Default Guide Installation, Optional
Wall Mounting Installation
|
|
Size
|
39(W) x 118(H) x 86(D) mm
|
|
Certificate
|
|
EMC
|
CE，FCC
|
|
EMI
|
FCC Part 15. CISPR(EN55022) class A
|
|
EMS
|
EN 61000-4-2（ESD）Level 3,
EN 61000-4-3（RS）Level 3,
EN 61000-4-4（EFT）Level 3,
EN 61000-4-5（Surge）Level 3,
EN 61000-4-6（CS）Level 3,
EN 61000-4-8
|
|
Shock
|
IEC60068-2-27
|
|
Freefall
|
IEC60068-2-32
|
|
Vibration
|
IEC60068-2-6
|
|
Green Product
|
RoHS, WEEE
|
|
Warranty
|
|
MTBF
|
380000h
|
|
Warranty period
|
5-year
|
Ordering information
|
Available Models
|
1000M Fiber Port
|
10/100/1000M Copper Port
|
Power Supply Range
|
|
HT302GI-8M0.5A/HT302GI-3SXX
|
1
|
2
|
12~48VDC
|
Appearance&Dimension
