Industrial Media Converter

Industrial Gigabit Ethernet-to-fiber media converter

Category : Industrial Ethernet > Industrial Media Converter

• Support 1*10/100/1000M Ethernet RJ45 port and 1*1000M optical port (SC/FC/LC optional)
•Electrical interface (RJ45 interface) supports 10/100/1000M self-adaptation, full/half-duplex mode, MDI/MDI-X auto-detection.
•Support IEEE802.3, IEEE802.3u, IEEE802.3x,IEEE802.3z Flow Control, IEEE802.3x Flow Control, Back Pressure Flow Control
•Support for LFP link disconnection alarms
•Ultra-low latency and resilient caching technology: "store-and-forward" mode, seamlessly connects devices at different rates, adaptive mode of operation
•Input voltage: DC 10~58V (dual power supply redundancy backup), power supply support overload protection, anti-reverse connection protection.
•Lightning protection level: power inlet and RJ45 electrical port are all four levels of lightning protection
•Comply with Industrial Class IV electromagnetic compatibility requirements
•Protection class: IP40, anti-surge static, DIN clamp rail, metal aluminum profile, fanless design
•Working temperature: -40 ℃ ~ + 85 ℃ (industrial-grade materials)
•Supports DIN-rail / wall mounting

Description
Parameter
Application
Download
Related

HT102I series industrial 10/100/1000M gigabit media converter support the conversion from 10/00/1000M copper to 1000M optical. Redundant power supply design, wide voltage range input, and provide overload and reverse protection. Wide temperature model can be selected, strong anti-electromagnetic interference ability, fully meet the harsh industrial application environment.

Highlights:

‧EMC Certified for Industrial Standards
‧4KV Surge Protection
High MTBF
‧Long Life Parts
‧Rigorous Standards
‧Strict Quality Checks in Factory
‧5 Years Warranty
‧Fan-less and Rugged Design

IEEE Standard
IEEE 802.3	10BaseT Ethernet
IEEE 802.3u	100BaseT(X) and 100BaseFX Fast Ethernet
IEEE 802.3ab	1000BaseT(X) Ethernet
IEEE 802.3z	1000BaseX Ethernet
IEEE 802.3x	Flow Control（flow control）

Switching Feature
MAC address table	2K
Packet Caching	1Mbit
Processing method	Store and forward

Interface
RJ45 port	x1
Fiber	x1, SM/MM optional, SC/ST/FC optional, dual fiber/single fiber optional
Fiber transmission distance	MM 550m/2km，SM 20km/40km/60km/80km/120km optional
LED	PWR, TP/Fx Link/Act, Fail

Power
24V input	6-Pin, dual power input, 12~48VDC wide range
220V input	6-Pin, dual power input, 85~264VAC/77~300VDC wide range
Power consumption	Max 3W
Power protection	Reverse connection protection and overload protection

Environment
Standard operation temperature	-10 ~ 60℃
Wide range operation temperature	-40 ~ 75℃
Storage temperature	-40 ~ 85°C
Relative humidity	5 ~ 95% (non-condensation)

Physical
Housing	IP40 Aluminium alloy
Installation way	Default Guide Installation, Optional Wall Mounting Installation
Size	39(W) x 118(H) x 86(D) mm

Certificate
EMC	CE，FCC
EMI	FCC Part 15. CISPR(EN55022) class A
EMS	EN 61000-4-2（ESD）Level 3, EN 61000-4-3（RS）Level 3, EN 61000-4-4（EFT）Level 3, EN 61000-4-5（Surge）Level 3, EN 61000-4-6（CS）Level 3, EN 61000-4-8
Shock	IEC60068-2-27
Freefall	IEC60068-2-32
Vibration	IEC60068-2-6
Green Product	RoHS, WEEE

Warranty
MTBF	380000h
Warranty period	5-year

Ordering information

Available Models	1000M Fiber Port	10/100/1000M Copper Port	Power Supply Range
HT102I-8M0.5A/3SXX	1	1	12~48VDC

Appearance&Dimensions
